SilverStone SST-RV02B-EW-USB3.0 [31/40] Top cover limitation
![SilverStone SST-RV02B-E [31/40] Top cover limitation](/views2/1713417/page31/bg1f.png)
30
SERIES
SERIES
The gap between I/O and top cover is 70mm
Acceptable connector
Unacceptable connector
70mm
Top cover limitation
