65
3.13.3 HTTP Server
The device also can send event message to specified HTTP server.
Name: User can specify multiple HTTP servers as wish. Therefore, user
needs to specify a name for each HTTP server setting.
URL: Type the server name or the IP address of the HTTP server.
Test: Check the HTTP server whether it is available or not.
HTTP Login name: Type the user name for the HTTP server.
HTTP Login Password: Type the password for the HTTP server.
Proxy Address: Type the server name or the IP address of the HTTP Proxy.
Proxy Login name: Type the user name for the HTTP Proxy.
Proxy Login Password: Type the password for the HTTP Proxy.
Proxy Port: Set port number of Proxy.
