Appendix H: Product Specification
Product
ICA-HM130
Video
Image Sensor
1.3 Mega-Pixel CMOS image sensor
Lens
4.3 mm, F1.8 fixed board
Illuminator
1.0V/lux-sec (550nm)
View Angle
H: 29 Degree / V: 22 Degree
Signal to Noise
44 dB
Video Codec
H.264 / MPEG-4 / M-JPEG
Video Resolution
H.264 SXGA / VGA / QVGA / QQVGA
MPEG4 VGA / QVGA / QQVGA
M-JPEG SXGA / VGA / QVGA / QQVGA
Image Control
AWB, AES
Audio Specification
Audio Codec
G.711 / G.726 / AMR
Audio I/O
Audio in: Internal Microphone / Audio out: External Speaker
Audio Streaming
One-Way or Two-way
Audio Output
Line Level out
Microphone
External microphone input
Network and Configuration
Network Interface
1 x RJ-45, 10/100Base-TX
Network Standard
IEEE 802.3, IEEE 802.3u, IEEE802.3af
Network Protocol
TCP/IP, HTTP, SMTP, FTP, NTP, DNS,
DDNS, DHCP, UPnP, RTSP, PPPoE, 3GPP
Browser / Software
Microsoft ® Internet Explorer 6.0 or later, Cam Viewer Plus Lite/Pro
Motion Detection
10 area definable
Environment Specifications
Power Requirement
12V DC, 1 A
IEEE 802.3af
Dimension (H xΦ)
110 x 131 mm
Weight
450 g
Operating Temperature
0 ~ 40 Degree C
Operating Humidity
20 ~ 80% (non-condensing)
Emission
CE, FCC
