7
1.3 Package Contents
User can find the following items in the package:
Internet Camera x 1
Power Adapter x 1
Mount Screws and Anchors x 3
User’s Manual CD x 1
Quick Installation Guide x 1
NOTE:
1. If any of the above items are missing, please contact your dealer immediately.
2. Using the power supply that is not the one included in Internet camera packet
will cause damage and void the warranty for this product.
