Planet ICA-110W [11/20] Camera utility ipview pro operation

Wireless Channel:

The pull down menu provides the wireless channel for commu-nication. A “channel”

is a range of frequencies to be used in communication between ICA-110W and Access

Point in infra-structure mode or ICA-110W and PC/Notebook in Ad-hoc mode. Select

the appropriate channel from the list provided depending on the regulatory region

that the unit is sold.

WEP Encryption:

The default setting for the Encryption Key is Disable. Therefore, to secure the wireless

transmission, be sure to enable this option.

WEP Key:

While enabling WEP Encryption, please select the encryption format ASCII or HEX

and enter the relevant data. Please refer to User’s Manual on bundled CD for detailed

information about conﬁguring WEP parameters.

Conﬁrm WEP Key:

Enter the same WEP Key to conﬁrm.

Save/Cancel:

After making sure all settings are correct, click on the “

Save” icon to store the settings for

Internet Camera. You can alternatively click on the “

Cancel” icon to restore all settings to

the values last saved to or retrieved from Internet Camera.

Camera Utility IPView Pro operation

As a standalone, network camera, you can use the web browser to view the images;

however, the software IPView Pro in the CD-ROM enables the system administrator up to

16 cameras centralized management

Installation

STEP 1

Insert the CD-ROM into the CD-ROM drive to initiate the autorun program. Once

completed a menu screen will appear as follows:
