Planet ICA-110W [3/20] Physical installation

Requirements

Note:

A faster CPU and dedicated computer / notebook can support more

Internet cameras and more image frames.

Model ICA-110/ICA-100C ICA-110W ICA-100PE

Network Environment

LAN 10/ 100M Ethernet 10/ 100M Ethernet

IEEE 802.11g Wireless

LAN

10/ 100M Ethernet

Power over Ethernet IEEE

802.3af

Monitoring System Recommended to Access Internet Camera

System Hardware • CPU: Intel Celeron 1.1GHz or above (Intel Pentium 4 is preferred)

• Memory Size: 128 MB or above

• VGA card resolution: 800x600 or above

Web Browser • Internet Explorer 5.0 or above (ActiveX & JAVA Mode – Image View for Win

dows OS and JAVA Mode – Image View for other OS)

• Netscape 6.0 or above (JAVA Mode – Image View)

System Requirement for IPView Pro Application

Support OS Win 98 / SE/ Me / 2000 / XP

System Hardware • CPU: Intel Celeron 1.1GHz or above (Intel Pentium 4 is preferred)

• Memory Size: 512 MB or above.

• VGA card resolution: 1024x768 or above

Physical Installation

ICA-110

1. Connect an Ethernet cable

Connect one end of an Ethernet cable to the LAN port located on the ICA-110 rear panel

and attach the other end to the network device (hub or switch).

2. Attach the external power supply

Connect the provided power adapter to the ICA-110's connector labeled “5VDC” on rear

panel.

3. Check the LEDs

The PWR and ACT LEDs should be on.
