PLANET Technology Corp. GRT-101/401/402 User’s Manual
- -
71
Download
Byte Transferred : 624641 bytes
Complete
Transfer Complete, Replace Now? (y/n): y
Writing flash....................... OK!
Do you want to reboot? (y/n): y
Be sure to write the new image to NVRAM and immediately reboot the device
to activate it. When you log back onto GRT series after the reboot, then you
can use the “show system” command to verify the version of the new firmware
that is active, and restore your configuration.
Note: All configurations will be cleared during the upgrading procedure. Make sure that you have a backup
configuration file before you start the upgrading procedure. See section 3.17.1 Backup configuration for details.
