Control Systems
5251
Advanced Control Systems
Features
One touch selection to total air comfort
Up to 2,560 groups (5,120 indoor units) can be controlled by one system
• Handy area settings simplify detailed management of VRV.
• Display of floor plans enables a quick search of desired air conditioning units.
• Operation history shows manner of control and origin in past operations of air conditioning
units.
Central control
• Remote access with a PC allows total air conditioning management using the same type of
screens as those displayed in the
intelligent Touch Manager
.
• Authorised users can centrally control individual air conditioning units from their own
computers.
Remote access
• VRVs are controlled automatically throughout the year by the schedule function.
• Interlocking VRVs and other equipment enables easy automation of building facilities operation.
• Setback adjusts temperature settings even when rooms are unoccupied.
Automatic control
• The Energy Navigator feature simplifies energy management by tracking energy consumption
data and identifying inefficient operation.
Energy management
• Contact information of maintenance contractors can be registered and displayed.
• E-mails are sent automatically to alert of malfunctions and potential trouble.
• The
intelligent Touch Manager
can link to the Air Conditioning Network Service System for 24-
hour monitoring of operating conditions and status.
Troubleshooting
• A single
intelligent Touch Manager
can manage a small building or be expanded to handle
medium- to large-sized buildings.
• Large building properties can also take advantage of the
iTM integrator
to link up and expand
system up to 5
intelligent Touch Managers
for integrated control.
Scalability
Air Conditioning
Network Service System
Web Access
Web Access
LAN
Max. 50m
iTM plus adaptor
line
Di/Pi port
Max. 500m
I/O expansion line
I/O System (Max. 30 modules)
iTM plus adaptor
(Max. 7 adaptors)
I/O moduleI/O module I/O module
Lighting
Pump
Fan
Sensor
Internet
Intranet
system overview
Max. 64 groups
Phone line
LAN
Internal modem
(option)
Fire alarm
Max. 200m
kWh meter
Di/Pi line
USB memory
line
DCM601A51
Daikin proudly introduces its new
intelligent Touch Manager
, a VRV system
controller featuring an array of simple, useful system management functions for
added value.
New
New
