Basic Control Si34-704
92 Function
represents the range in which “Hz” is not stepped up.
RXQ28PY1, 30PY1 (10/12+18HP)
(To increase Step No.)
STEP
No.
Master
unit
INV
Slave
unit
INV
STD
1 52 Hz 52 Hz OFF
2 56 Hz 56 Hz OFF
3 62 Hz 62 Hz OFF
4 66 Hz 66 Hz OFF
5 70 Hz 70 Hz OFF
6 74 Hz 74 Hz OFF
7 80 Hz 80 Hz OFF
8 88 Hz 88 Hz OFF
9 96 Hz 96 Hz OFF
10 104 Hz 104 Hz OFF
11 110 Hz 110 Hz OFF
12 116 Hz 116 Hz OFF
13 124 Hz 124 Hz OFF
14 132 Hz 132 Hz OFF
15 144 Hz 144 Hz OFF
16 158 Hz 158 Hz OFF
17 166 Hz 166 Hz OFF
18 176 Hz 176 Hz OFF
19 80 Hz 80 Hz ON 1
20 88 Hz 88 Hz ON 1
21 96 Hz 96 Hz ON 1
22 104 Hz 104 Hz ON 1
23 116 Hz 116 Hz ON 1
24 124 Hz 124 Hz ON 1
25 132 Hz 132 Hz ON 1
26 88 Hz 88 Hz ON 2
27 96 Hz 96 Hz ON 2
28 104 Hz 104 Hz ON 2
29 124 Hz 124 Hz ON 2
30 144 Hz 144 Hz ON 2
31 92 Hz 92 Hz ON 3
32 104 Hz 104 Hz ON 3
33 116 Hz 116 Hz ON 3
34 124 Hz 124 Hz ON 3
35 144 Hz 144 Hz ON 3
36 158 Hz 158 Hz ON 3
37 166 Hz 166 Hz ON 3
38 176 Hz 176 Hz ON 3
39 188 Hz 188 Hz ON 3
40 202 Hz 202 Hz ON 3
41 210 Hz 210 Hz ON 3
42
210 Hz 218 Hz ON 3
43 210 Hz 232 Hz ON 3
44 210 Hz 248 Hz ON 3
45
210 Hz 266 Hz ON 3
Notes:
1. INV : Inverter compressor
STD : Standard compressor
Figures after ON represent the number of STD compressors in operation.
2. “Master unit”, and “slave unit” in this section are the names for control, and they will be transferred according to the
priority of rotation system.
3. Depending on the operating conditions of compressors, the compressors may run in patterns other than those
aforementioned.
(To decrease Step No.)
STEP
No.
Master
unit
INV
Slave
unit
INV
STD
1 52 Hz OFF OFF
2 56 Hz OFF OFF
3 62 Hz OFF OFF
4 68 Hz OFF OFF
5 74 Hz OFF OFF
6 80 Hz OFF OFF
7 88 Hz OFF OFF
8 96 Hz OFF OFF
9 104 Hz OFF OFF
10 52 Hz 52 Hz OFF
11 56 Hz 56 Hz OFF
12 62 Hz 62 Hz OFF
13 66 Hz 66 Hz OFF
14 70 Hz 70 Hz OFF
15 74 Hz 74 Hz OFF
16 80 Hz 80 Hz OFF
17 88 Hz 88 Hz OFF
18 92 Hz 92 Hz OFF
19 96 Hz 96 Hz OFF
20 104 Hz 104 Hz OFF
21 110 Hz 110 Hz OFF
22 116 Hz 116 Hz OFF
23 124 Hz 124 Hz OFF
24 132 Hz 132 Hz OFF
25 52 Hz 52 Hz ON 1
26 62 Hz 62 Hz ON 1
27 68 Hz 68 Hz ON 1
28 74 Hz 74 Hz ON 1
29 80 Hz 80 Hz ON 1
30 88 Hz 88 Hz ON 1
31 96 Hz 96 Hz ON 1
32 104 Hz 104 Hz ON 1
33 52 Hz 52 Hz ON 2
34 62 Hz 62 Hz ON 2
35 74 Hz 74 Hz ON 2
36 88 Hz 88 Hz ON 2
37 96 Hz 96 Hz ON 2
38 52 Hz 52 Hz ON 3
39 62 Hz 62 Hz ON 3
40 74 Hz 74 Hz ON 3
41 92 Hz 92 Hz ON 3
42 104 Hz 104 Hz ON 3
43 116 Hz 116 Hz ON 3
44 124 Hz 124 Hz ON 3
45 144 Hz 144 Hz ON 3
46 158 Hz 158 Hz ON 3
47 166 Hz 166 Hz ON 3
48 176 Hz 176 Hz ON 3
49 188 Hz 188 Hz ON 3
50 202 Hz 202 Hz ON 3
51 210 Hz 210 Hz ON 3
52
210 Hz 218 Hz ON 3
53 210 Hz 232 Hz ON 3
54
210 Hz 248 Hz ON 3
55 210 Hz 266 Hz ON 3
RXQ 32PY1 (16+16HP)
(To increase Step No.)
STEP
No.
Master
unit
INV
Slave
unit
INV
STD
1 52 Hz 52 Hz OFF
2 56 Hz 56 Hz OFF
3 62 Hz 62 Hz OFF
4 66 Hz 66 Hz OFF
5 70 Hz 70 Hz OFF
6 74 Hz 74 Hz OFF
7 80 Hz 80 Hz OFF
8 88 Hz 88 Hz OFF
9 96 Hz 96 Hz OFF
10 104 Hz 104 Hz OFF
11 110 Hz 110 Hz OFF
12 116 Hz 116 Hz OFF
13 124 Hz 124 Hz OFF
14 132 Hz 132 Hz OFF
15 144 Hz 144 Hz OFF
16 158 Hz 158 Hz OFF
17 166 Hz 166 Hz OFF
18 176 Hz 176 Hz OFF
19 80 Hz 80 Hz ON 1
20 88 Hz 88 Hz ON 1
21 96 Hz 96 Hz ON 1
22 104 Hz 104 Hz ON 1
23 116 Hz 116 Hz ON 1
24 124 Hz 124 Hz ON 1
25 132 Hz 132 Hz ON 1
26 88 Hz 88 Hz ON 2
27 96 Hz 96 Hz ON 2
28 104 Hz 104 Hz ON 2
29 124 Hz 124 Hz ON 2
30 144 Hz 144 Hz ON 2
31 92 Hz 96 Hz ON 3
32 104 Hz 104 Hz ON 3
33 116 Hz 116 Hz ON 3
34 124 Hz 124 Hz ON 3
35 144 Hz 144 Hz ON 3
36 96 Hz 96 Hz ON 4
37 104 Hz 104 Hz ON 4
38 116 Hz 116 Hz ON 4
39 124 Hz 124 Hz ON 4
40 144 Hz 144 Hz ON 4
41 158 Hz 158 Hz ON 4
42 166 Hz 166 Hz ON 4
43 176 Hz 176 Hz ON 4
44 188 Hz 188 Hz ON 4
45 202 Hz 202 Hz ON 4
46 210 Hz 210 Hz ON 4
(To decrease Step No.)
STEP
No.
Master
unit
INV
Slave
unit
INV
STD
1 52 Hz OFF OFF
2 56 Hz OFF OFF
3 62 Hz OFF OFF
4 68 Hz OFF OFF
5 74 Hz OFF OFF
6 80 Hz OFF OFF
7 88 Hz OFF OFF
8 96 Hz OFF OFF
9 104 Hz OFF OFF
10 52 Hz 52 Hz OFF
11 56 Hz 56 Hz OFF
12 62 Hz 62 Hz OFF
13 66 Hz 66 Hz OFF
14 70 Hz 70 Hz OFF
15 74 Hz 74 Hz OFF
16 80 Hz 80 Hz OFF
17 88 Hz 88 Hz OFF
18 92 Hz 92 Hz OFF
19 96 Hz 96 Hz OFF
20 104 Hz 104 Hz OFF
21 110 Hz 110 Hz OFF
22 116 Hz 116 Hz OFF
23 124 Hz 124 Hz OFF
24 132 Hz 132 Hz OFF
25 52 Hz 52 Hz ON 1
26 62 Hz 62 Hz ON 1
27 68 Hz 68 Hz ON 1
28 74 Hz 74 Hz ON 1
29 80 Hz 80 Hz ON 1
30 88 Hz 88 Hz ON 1
31 96 Hz 96 Hz ON 1
32 104 Hz 104 Hz ON 1
33 52 Hz 52 Hz ON 2
34 62 Hz 62 Hz ON 2
35 74 Hz 74 Hz ON 2
36 88 Hz 88 Hz ON 2
37 96 Hz 96 Hz ON 2
38 52 Hz 52 Hz ON 3
39 62 Hz 62 Hz ON 3
40 74 Hz 74 Hz ON 3
41 92 Hz 92 Hz ON 3
42 104 Hz 104 Hz ON 3
43 52 Hz 52 Hz ON 4
44 62 Hz 62 Hz ON 4
45 74 Hz 74 Hz ON 4
46 96 Hz 96 Hz ON 4
47 104 Hz 104 Hz ON 4
48 116 Hz 116 Hz ON 4
49 124 Hz 124 Hz ON 4
50 144 Hz 144 Hz ON 4
51 158 Hz 158 Hz ON 4
52 166 Hz 166 Hz ON 4
53 176 Hz 176 Hz ON 4
54 188 Hz 188 Hz ON 4
55 202 Hz 202 Hz ON 4
56 210 Hz 210 Hz ON 4
