Specifications Si34-704
20 Specifications
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) RXQ30PY1 RXQ32PY1
Model Name (Independent Unit) RXQ12PY1+RXQ18PY1 RXQ16PY1+RXQ16PY1
★
1 Cooling Capacity (19.5°CWB)
kcal / h 71,400 77,800
Btu / h 283,000 309,000
kW 83.0 90.5
★2 Cooling Capacity (19.0°CWB)
kW
82.5 90.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1680×1240×765)+(1680×1240×765) (1680×1240×765)+(1680×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.53)+(13.72+10.53+10.53) (13.72+10.53+10.53)+(13.72+10.53+10.53)
Number of Revolutions r.p.m (6300, 2900)+(7980, 2900, 2900) (6480, 2900×2)+(6480, 2900, 2900)
Motor Output×Number
of Units
kW (2.5+4.5)×1+(3.0+4.5+4.5)×1 (1.4+4.5+4.5)×1+(1.4+4.5+4.5)×1
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.35×2)+(0.75×2) (0.35×2)+(0.35×2)
Air Flow Rate m³/min 233+239 233+233
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
19.1 (Brazing Connection)
φ
19.1 (Brazing Connection)
Gas Pipe mm
φ
34.9 (Brazing Connection)
φ
34.9 (Brazing Connection)
Product Mass (Machine Weight) kg 285+341 329+329
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Capacity Control % 5~100 5~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 10.0+12.7 12.5+12.5
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
