4. Hardware Connection

o n

Steps Description

1 Connect NAS-7201 and a Switch, Hub, Router, or computer with RJ-45 Ethernet cable.

2 Connect USB printer(s) or USB storage device(s) to this device with USB cable(s). NAS-7201 can

automatically mount the USB devices connected.

3 Connect the power supply to NAS-7201.

4 Press the “Power button” to turn on NAS-7201. The HDD activate LED on the front panel will ligh

up during booting-up. NAS-7201 will be ready to use when the blue LED lights up steadily.

- 8 -
