Planet IFT-802 [6/18] Dimension w x d x h
![Planet IFT-802 [6/18] Dimension w x d x h](/views2/1071814/page6/bg6.png)
TX: 10/100(Green)
Link (Green)
Half/Full Duplex (Orange)
Power Supply 12~48 VDC, Redundant power with polarity reverse and overlap current protection
function
Power Consumption 4.6 Watts
Installation Provide DIN rail kit and wall mount plate for 3-way installation
Operating environment 0~60 Degree C, 5%~90%RH (Non-condensing)
Storage environment -40~85 Degree C, 5%~90%RH (Non-condensing)
Dimension (W x D x H) 54 × 105 × 155 mm
Emission FCC Class A, CE mark
Stability testing IEC60068-2-32(Free fall), IEC60068-2-27(Shock), IEC60068-2-6(Vibration)
