2.1.3 LED Indications

There are 9 diagnostic LEDs located on the Front panel of industrial media converter. They provide

real-time information of system and optional status. The following table provides description of the LED

status and their meanings for the industrial media converter.

LED Status Meaning

Green When the IFT-802 has power input s the LED will light on

Power

Off No any power inputs

Green Power on

Power 1

Off No power inputs

Green Power on

Power 2

Off No power inputs

Orange Power failure or UTP port failure or Fiber port failure

Fault

Off

No Power failure or UTP port failure or Fiber port failure occurs or the

port alarm disable

Green The port is linking with its link partner.

Blinks The port is transmitting or receiving packets from the FX device.

LNK/ACT(Fiber)

Off No device attached

Orange The port is operating in full-duplex mode.

FDX (Fiber)

Off Half-duplex mode or no device attached

Green In 100Mbps transmitting speed

10/100(UTP)

Off In 10Mbps transmitting speed

Green The port is linking with its link partner.

Blinks The unit is transmitting or receiving packets from the devices.

LNK/ACT(UTP)

Off No device attached

Orange The port is operating in full-duplex mode.

FDX (UTP)

Off Half-duplex mode or no device attached
