SilverStone ET450-B [10/16] Protection
![SilverStone SST-ET550-B [10/16] Protection](/views2/1718819/page10/bga.png)
08
20ms max at full load.
2.7 RISE TIME
+3.3V output 4.5 Vmax.
+5.0V output 7.0 Vmax.
+12.0V output 15.6 Vmax.
3.1 OVER VOLTAGE PROTECTION
ET750-B(V1.0)
ET450-B(V1.1)/ET550-B(V1.1)/ET650-B(V1.1)/ET650-B(V1.2)
ET450-B(V1.0)/ET550-B(V1.0)/ET650-B(V1.0)
All output to GND.
3.2 SHORT PROTECTION
Foldback at 110%~150% over peak load
3.3 OVER POWER PROTECTION
Protection temperature is 38℃ to 43℃ at 115V and full load
3.4 OVER CURRENT PROTECTION
3.5 OVER TEMPERATURE PROTECTION
3.0 PROTECTION:
When OVP ,OPP or short protection is triggered, the main outputs will be latched
off. The main outputs can be reset by cycling the DC remote on/off or AC power.
+5Vsb output is auto recovery when fault condition removed.
When OVP ,OPP ,OCP,OTP or short protection is triggered, the main outputs will
be latched off. The main outputs can be reset by cycling the DC remote on/off or
AC power. +5Vsb output is auto recovery when fault condition removed.
0 ℃ to +40 ℃
4.1 OPERATING TEMP
-20 ℃ to +70 ℃
4.2 STORAGE TEMP
20% to 90%,non-condensing
4.3 OPERATING HUMIDITY
5% to 95%, non-condensing
4.4 STORAGE HUMIDITY
0 to 10,000 feet
4.5 OPERATING ALTITUDE
0 to 50,000 feet
4.6 STORAGE ALTITUDE
4.0 ENVIRONMENT:
