1.6 LEAKAGE CURRENT

1.7 POWER FACTOR

2. OUTPUT

3.5mA max.

PF > 0.96 at 230Vac input and full load

＊ The continuous total output power is 450W max.

• The combined power of +5V and +3.3V is 100W max.

• Peak currents may last up to 12 seconds with not more than one occurrence per minute.

＊ Add 0.1uF and 10uF capacitors across output terminal during ripple & noise test.

＊ LOAD REGULATION TEST TABLE:

1.8 NO LOAD CONSUMPTION

<0.7W

ET450-B / ET550-B / ET650-B

Meet ErP 2013 requirement

ET750-B

ET450-B

Voltage

+5V +3.3V +12V -12V +5Vsb

＊

Max load

15.0A 16.0A 34.0A 0.3A 2.5A

Min load

0.5A 0.3A 1.0A 0.0A 0.0A

Peak load

-- -- -- -- 3.0A

＊



Combined power

100W -- -- --

＊



Regulation

+5,-5% +5,-5% +5,-5% +10,-10% +5,-5%

＊



Ripple & Noise

50mV 50mV 120mV 120mV 50mV

Loading +12V +5V +3.3V -12V +5Vsb

Required minimum

efficiency

20% 10.57A 2.46A 2.46A 0.05A 0.43A 82%

50% 26.42A 6.16A 6.16A 0.13A 1.07A 85%

100% 52.83A 12.32A 12.32A 0.26A 2.13A 82%

ET750-B
