+5V +12V +3.3V -12V +5Vsb
0.5A 1.0A 0.3A 0.0A 0.0A
6.0A 2.0A 6.0A 0.0A 0.1A
12.0A 7.0A 11.0A 0.1A 0.5A
16.0A 16.0A 9.0A 0.2A 1.0A
10.0A 22.0A 18.0A 0.2A 1.5A
6.0A 38.0A 10.0A 0.3A 2.5A
8.0A 42.0A 0.3A 0.3A 0.5A
0.5A 2.0A 0.3A 0.0A 0.0A
LOAD1
LOAD2
LOAD3
LOAD4
LOAD5
LOAD6
LOAD7
LOAD8
＊ The continuous total output power is 650W max.
• The combined power of +5V and +3.3V is 120W max.
• Peak currents may last up to 12 seconds with not more than one occurrence per minute.
＊ Add 0.1uF and 10uF capacitors across output terminal during ripple & noise test.
＊ LOAD REGULATION TEST TABLE:
ET650-B
Voltage
+5V +3.3V +12V -12V +5Vsb
＊
Max load
17.0A 20.0A 50.0A 0.3A 2.5A
Min load
0.5A 0.3A 1.0A 0.0A 0.0A
Peak load
-- -- -- -- 3.0A
＊
Combined power
120W -- -- --
＊
Regulation
+5,-5% +5,-5% +5,-5% +10,-10% +5,-5%
＊
Ripple & Noise
50mV 50mV 120mV 120mV 50mV
