1.2 FREQUENCY
47Hz ~ 63Hz
1.3 CURRENT
ET450-B 115Vac/7.0A max. 230Vac/3.5A max
ET550-B 115Vac/8.0A max. 230Vac/4.0A max
ET650-B/ ET750-B 115Vac/10.0A max. 230Vac/5.0A max.
1.5 POWER EFFICIENCY
Meet 80 Plus Bronze requirement at 115Vac input.
ET450-B
ET550-B
ET650-B
1.4 INRUSH CURRENT
Power no damage at AC input 230Vac and 25 C cold start.
Loading +12V +5V +3.3V -12V +5Vsb
Required minimum
efficiency
20% 5.84A 2.02A 2.15A 0.05A 0.43A 82%
50% 14.60A 5.04A 5.37A 0.13A 1.07A 85%
100% 29.19A 10.08A 10.75A 0.26A 2.15A 82%
Loading +12V +5V +3.3V -12V +5Vsb
Required minimum
efficiency
20% 7.33A 2.20A 2.48A 0.05A 0.44A 82%
50% 18.33A 5.51A 6.20A 0.13A 1.09A 85%
100% 36.66A 11.02A 12.40A 0.26A 2.18A 82%
Loading +12V +5V +3.3V -12V +5Vsb
Required minimum
efficiency
20% 8.83A 2.39A 2.81A 0.05A 0.44A 82%
50% 22.08A 5.96A 7.02A 0.13A 1.10A 85%
100% 44.15A 11.93A 14.03A 0.26A 2.21A 82%
02
