4.1 Over Current Protection
This power supply shall have current limit to prevent the +5V, +3.3V, and +12V outputs
from exceeding the values shown in table 14. The current limit shall not trip under
maximum continuous load or peak loading as described in Table 5. The power supply shall
latch off if the current exceeds the limit. The latch shall be cleared by toggling the PSON#
signal or by cycling the AC power. The power supply shall not be damaged from repeated
power cycling in this condition. The -12V and +5VSB outputs shall be shorted circuit
protected so that no damage can occur to the power supply.
Table 14 -Over Current protection
4.2 Over Voltage Protection
The power supply shall shut down in a latch off mode when the output voltage exceeds the
over voltage limit shown in Table 4.
Table 15 -Over Voltage protection
4.3 Short Circuit Protection
The power supply shall shut down in a latch off mode when the output voltage is short
circuit.
4.4 No Load Operation
When the primary power is applied, with no load on any output voltage, no damage or
hazardous conditions shall occur. In such a case, the power supply shall power up and
stabilize.
+5V
+12V
+3.3V
Voltage Minimum Maximum Shutdown Mode
Latch Off
Latch Off
Latch Off
110%
110%
110%
150%
150%
150%
+5V
+12V
+3.3V
Voltage Minimum Maximum Shutdown Mode
Latch Off
Latch Off
Latch Off
+5.6V
+3.8V
+13.6V
+6.5V
+4.5V
+14.5V
09
