6. Agency Requirements
6.1 Safety Certification.
6.2 Input Leakage Current
Input leakage current from line to ground will be less than 3.5mA rms. Measurement will be
made at 240 VAC and 60Hz.
6.3 Production Line Testing
100% of the power supply production must have the following test performed. Each power
shall be marked indicating the testing was done and passed. Typically this is done by
stamping or labeling the power supply with "Hi-pot test OK".
6.4 Hi-Pot Testing
Each power supply must be Hi-pot tested according UL and TUV requirements, Minimum
typical testing voltage for Hi-pot testing are 1500Vac or 2121Vdc. However depending on
the power supply design the testing voltage May be higher. If higher the power supplies
shell be at the higher value.
6.5 Ground Continuity Testing
UL and TUV require that each power supply ground is tested, to ensure there is continuity
between the ground inlet of the power supply and the power supply chassis. This can be
performed with an ohm meter, or an electronic circuit that lights up and illustrates the
ground has continuity. Based on EN50116, ERG or TUV require that each power supply
ground id tested with a 25Amp ground test.
Product Safety
UL 60950 2000Edition, IEC60950, 3rd Edition
EU Low Voltage Directive(73/23/EEC) (CE)
TUV
RFI Emission
FCC Part15 (Radiated & Conducted Emissions)
CISPR 22,3rd Edition/ EN55022 Class B)
PFC Harmonic
EN 61000-3-2
Flicker
EN 61000-3-3
Immunity against
EN55024: 1998
-Electrostatic discharge
-IEC 61000-4-2 Min. 4kV contact discharge
Min. 8kV air discharge
-Radiated field strength
-IEC 61000-4-3 Min. 10V/m
-Fast transients
-IEC 61000-4-4 Min 2kV AC input lines
Min 1kV on data lines
-Surge voltage
-IEC 61000-4-5 Min 2kV common mode
Min 1kV differential mode
-RF Conducted -IEC 61000-4-6
-Voltage Dips and Interruptions
-IEC 61000-4-11
