SilverStone ST46GF [4/16] Dc output specification

2.9 Electrical Discharge, IEC61000-4-2

In addition to IEC61000-4-2, the following ESD tests should be conducted. Each surface

area of the unit under test should be subjected to twenty (20) successive static discharges, at

each of the follow voltages: 2KV, 3KV, 4KV, 5KV, 6KV and 8KV.

All power supply outputs shall continue to operate within the parameters of this

specification, without glitches or interruption, while the power is operating as defined and

subjected to 2kV through 10kV ESD pulses. The direct ESD event shall not cause any out of

regulation conditions such as overshoot or undershoot. The power supply shall withstand

these shocks without nuisance trips of the Over-Voltage Protection, Over-Current Protection,

or the remote +5VDC, +12VDC shutdown circuitry.

2.10Radiated Immunity, IEC61000-4-3

3. DC Output Specification

3.1 Output Current / Loading

The following tables define two power and current rating. The power supply shall

meet both static and dynamic voltage regulation requirements for minimum load

condition.

Table 5 - Load Range 1

Note 1: The +5 & +3.3 Volt total output shall not exceed 150 W.

Note 2: The +5, +3.3 & +12Volt total output shall not exceed 440W.

Note 3: Maximum continues total DC output power shout not exceed 460W.

Table 6 - Load Range 2

Frequency Electric Field Strength

27 MHz to 500 MHz un-modulated 3 V/m

Min. Load 0.1A0.1A2.5A2A

+5V +5VSB +12V -12V+3.3VOutput Voltage

2A0.8A30A

25A 25AMax. Load

Min. Load 0A0A1A1A

+5V +5VSB +12V -12V+3.3VOutput Voltage

1A0.4A15A

13A 13AMax. Load
