![SilverStone ST46GF [11/16] Environmental requirements](/views2/1720232/page11/bgb.png)
ST46GF
5. Environmental Requirements
5.1 Temperature
5.2 Humidity
5.3 Altitude
5.4 Mechanical Shock
The power supply (non-operating) shall not be damaged during a shock of 50G with an 11
mS half sin wave when non-operating. The shock to be applied in each of the orthogonal
axes.
5.5 Vibration (Operating and Non-operating)
The power supply shall be subjected to a vibration test consisting of a 10 to 300 Hz sweep at
a constant acceleration of 2.0g for duration of one (1) hour for each of the perpendicular
axes X, Y and Z,
1. 0.1 octave/minute. The output voltages shall remain within specification.
5.6 Acoustic Noise
The power supply shall be tested in accordance with specifications. The overall sound is
measured with the noise meter placed 1 meter from the nearest vertical surface of center of
fan installed in power supply.
CONDITIONS LIMITS:
115 VAC Input, full load of +5V Acoustic noise is 49 db maximum , 1A of +12V.
Operating Temperature Range 08C ~ 408C (328F ~ 1048F)
Non-Operating Temperature Range
-408C ~ 708C (-408F ~ 1588F)
Operating Temperature Range
Non-Operating Temperature Range
20%~90%RH non-condensing
5%~95%RH non-condensing
Operating Temperature Range
Non-Operating Temperature Range
Sea level to 10,000 ft
Sea level to 40,000 ft
