Daikin FTXJ35MV1BW [7/40] Open the upper front panel

Daikin FTXJ35MV1BS [7/40] Names of parts

Panel support plate

Back of the upper front panel

Silver particle ﬁ lter

(Ag-ion ﬁ lter)

Names of Parts

Outdoor Unit

• Appearance of the outdoor unit may differ from some models.

 Open the upper front panel

Air ﬁ lter

Titanium apatite

deodorizing ﬁ lter

Refrigerant piping and

inter-unit wiring

Earth terminal

• It is inside of this cover.

Drain hose

Air inlet

(back and side)

Air outlet

Outdoor temperature

sensor (back)

Model name plate

Lower front panel

• Note: the position of both

ﬁ lters is interchangeable.
