Functions SiBE061121_A
2 List of Functions
1. Functions
Category Functions
FVXG25/35K2V1B
RXG25/35K2V1B
FVXG50K2V1B
RXG50K2V1B
Category Functions
FVXG25/35K2V1B
RXG25/35K2V1B
FVXG50K2V1B
RXG50K2V1B
Basic
Function
Inverter (with inverter power control)
zz
Health &
Clean
Air-purifying filter — —
Operation limit for cooling (°CDB)
10
~ 46
10
~ 46
Photocatalytic deodorizing filter — —
Operation limit for heating (°CWB)
–15
~ 18
–15
~ 18
Air-purifying filter with photocatalytic
deodorizing function
——
PAM control
zz
Titanium apatite photocatalytic
air-purifying filter
zz
Standby electricity saving
z
—
Compressor Oval scroll compressor — — Air filter (prefilter)
zz
Swing compressor
zz
Wipe-clean flat panel — —
Rotary compressor — — Washable grille — —
Reluctance DC motor
zz MOLD PROOF operation — —
Comfortable
Airflow
Power-airflow flap — — Good-sleep cooling operation — —
Power-airflow dual flaps — — Timer WEEKLY TIMER operation
zz
Wide-angle louvers zz 24-hour ON/OFF TIMER zz
Vertical auto-swing (up and down)
zz
NIGHT SET mode
zz
Horizontal auto-swing (right and left) — — Worry Free
“Reliability &
Durability”
Auto-restart (after power failure) zz
3-D airflow — — Self-diagnosis (digital, LED) display zz
Comfort
Control
Auto fan speed
zz
Wiring error check function — —
Indoor unit quiet operation
zz
Anti-corrosion treatment of outdoor
heat exchanger
zz
NIGHT QUIET mode (automatic) — —
OUTDOOR UNIT QUIET operation
(manual)
zz
Flexibility
Multi-split / split type compatible indoor
unit
zz
INTELLIGENT EYE operation — — H/P, C/O compatible indoor unit — —
Quick warming function (preheating
operation)
zz Flexible power supply correspondence — —
Hot-start function
zz Chargeless 10 m 10 m
Automatic defrosting
zz
Either side drain (right or left) — —
Operation Automatic operation
zz
Power selection — —
RADIANT operation
zzRemote
Control
5-room centralized controller (option) zz
Program dry operation zz
Remote control adaptor (normal open
pulse contact) (option)
zz
Fan only zz
Lifestyle
Convenience
New POWERFUL operation
(non-inverter)
——
Remote control adaptor (normal open
contact) (option)
zz
Inverter POWERFUL operation zz
DIII-NET compatible (adaptor) (option) zz
Priority-room setting — —
COOL / HEAT mode lock — — Remote
Controller
Wireless
zz
HOME LEAVE operation — — Wired (option) zz
ECONO operation zz
Indoor unit [ON/OFF] button
zz
Signal receiving sign zz
R/C with back light zz
Temperature display — —
Note:
z
: Holding Functions
— : No Functions
