Specifications SiBE061121_A
8 Specifications
Note:
The data are based on the conditions shown in the table below.
50 Hz, 220 - 230 - 240 V
Model
Indoor Unit FVXG50K2V1B
Outdoor Unit
RXG50K3V1B
Cooling Heating
Capacity Rated (Min. ~ Max.)
kW 5.0 (1.7 ~ 5.6) 5.8 (1.7 ~ 8.1)
Btu/h 17,100 (5,800 ~ 19,100) 19,800 (5,800 ~ 27,600)
kcal/h 4,300 (1,460 ~ 4,820) 4,990 (1,460 ~ 6,970)
Moisture Removal L/h 2.9
—
Running Current (Rated) A 7.1 - 6.7 - 6.5 7.3 - 7.0 - 6.7
Power Consumption
Rated (Min. ~ Max.)
W 1,520 (450 ~ 2,000) 1,580 (500 ~ 2,660)
Power Factor % 97.3 - 98.6 - 97.4 98.4 - 98.1 - 98.3
COP (Rated) W/W 3.29 (3.78 - 2.80) 3.67 (3.40 - 3.05)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 12.7
Drain mm φ 18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Unit FVXG50K2V1B
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
10.6 (374) 12.2 (431)
M 8.9 (314) 10.0 (353)
L 7.3 (258) 7.8 (275)
SL 6.0 (212) 6.8 (240)
Fan
Type Cross Flow Fan
Motor Output W 32
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Upward
Air Filter Removable / Washable / Mildew Proof
Running Current A 0.17 - 0.16 - 0.15 0.18 - 0.17 - 0.17
Power Consumption W 32 - 32 - 32 35 - 35 - 35
Power Factor % 85.6 - 87.0 - 88.9 88.4 - 89.5 - 85.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 600 × 950 × 215
Packaged Dimensions (H × W × D) mm 761 × 1,030 × 314
Weight kg 22
Gross Weight kg 28
Sound
Pressure
Level
H / M / L / SL dB(A) 44 / 40 / 36 / 32 46 / 40 / 34 / 30
Sound Power Level dB 58 60
Outdoor Unit RXG50K3V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC36BXD
Motor Output W 1,100
Refrigerant
Oil
Type FVC50K
Charge L 0.65
Refrigerant
Type R-410A
Charge kg 1.6
Airflow Rate
H
m³/min
(cfm)
50.9 (1,797) 45.0 (1,589)
SL 48.9 (1,727) 43.1 (1,522)
Fan
Type Propeller
Motor Output W 53
Running Current A 6.93 - 6.54 - 6.35 7.12 - 6.83 - 6.53
Power Consumption W 1,488 - 1,488 - 1,488 1,545 - 1,545 - 1,545
Power Factor % 97.6 - 98.9 - 97.6 98.6 - 98.4 - 98.6
Starting Current A 7.3
Dimensions (H × W × D) mm 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 797 × 992 × 390
Weight kg 47
Gross Weight kg 52
Sound
Pressure
Level
H / SL dB(A) 48 / 44 48 / 45
Sound Power
Level
HdB 63 63
Drawing No. 3D080644
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
