SPECIFICATION
STRIDER GOLD EVOLUTION SERIES
SST-ST1200-G Evolution
SST-ST1000-G Evolution
SST-ST85F-G Evolution
SST-ST75F-G Evolution
01
ATX12V / EPS 12V Switching Power Supply
With Active PFC
80Plus Gold
PS/2
1. AC INPUT
1.1 AC input requirements
Table 1 AC Input Line Requirements
Power factor correction (PF)>0.90 at full load.
This specification describes the requirements of 750W、850W、1000W、1200W
switching power supply with an stretch ATX form-factor and EPS12V, +5V standby
voltage, remote on/off control, full range line input capability and forced air cooling
characteristics.
The input voltage, current, and frequency requirements for continuous operation are
stated below.
Parameter Min. Nom. Max. Unit
Vin( Full range ) 90 100-240 264 VACrms
Vin(Full range,1200W) 103 115-240 264 VACrms
Vin Frequency 47 60-50 63 Hz
Iin(750W) 9.5-4.8 Arms
Iin(850W) 11-5.5 Arms
Iin(1000W,1200W) 12-6 Arms
The power supply must meet inrush requirements for any rated AC voltage, during
turn on at any phase of AC voltage, during a single cycle AC dropout condition,
during repetitive ON/OFF cycling of AC, and over the specified temperature range
(Top). The peak inrush current shall be less than the ratings of its critical
components (including input fuse, bulk rectifiers, and surge limiting device).
02
STRIDER GOLD EVOLUTION SERIES
2. DC OUTPUT
2.1 DC voltage regulation
2.2 Load ranges
2.2.1: (ST75F-G Evolution Load Range)
2.2.2: (ST85F-G Evolution Load Range)
Parameter Range Min. Nom. Max. Unit
+3.3V +/-3% +3.20 +3.30 +3.40 Volts
+5V +/-3% +4.85 +5.00 +5.15 Volts
+12V +/-3% +11.64 +12.00 +12.36 Volts
-12V +/-10% -13.20 -12.00 -10.80 Volts
+5VSB +/-3% +4.85 +5.00 +5.15 Volts
Parameter Min. Max. Unit
+3.3V 0.3 22 Amps
+5V 0.3 25 Amps
+12V 0.1 62 Amps
-12V 0 0.3 Amps
+5VSB 0.1 3.5 Amps
1.Maximum continuous total DC output power should not exceed 750W.
2.Maximum continuous combined load on +3.3VDC and +5VDC outputs shall not
exceed 150W.
3.Maximum current for +12V outputs shall be 62A(744W).
4.Maximum peak total DC output power should not exceed 850W.
5.Peak power and current loading shall be supported for a minimum of 12 second.
6.When +12V is load to 28A , -12V minimum load is 0.02A.
Parameter Min. Max. Unit
+3.3V 0.3 22 Amps
+5V 0.3 25 Amps
+12V 0.1 70 Amps
-12V 0 0.3 Amps
+5VSB 0.1 3.5 Amps
