SilverStone ST75F-G-E [6/6] St1200 g evo p135 說明書 p9 p10
![SilverStone SST-ST85F-G-E [6/6] St1200 g evo p135 說明書 p9 p10](/views2/1719285/page6/bg6.png)
09
9.2 Connectors
M/B 24PIN connector
Signal Pin Pin Signal
Orange +3.3V 13 1 +3.3V Orange
Blue -12VDC 14 2 +3.3V Orange
Black COM 15 3 COM Black
Green PS-ON 16 4 +5VDC Red
Black COM 17 5 COM Black
Black COM 18 6 +5VDC Red
Black COM 19 7 COM Black
White N/C 20 8 PWRGOOD Grey
Red +5VDC 21 9 +5Vsb Purple
Red +5VDC 22 10 +12V Yellow
Red +5VDC 23 11 +12V Yellow
Black COM 24 12 +3.3V Orange
EPS 12V 8PIN connector
Signal Pin Pin Signal
Yellow +12V 5 1 COM Black
Yellow +12V 6 2 COM Black
Yellow +12V 7 3 COM Black
Yellow +12V 8 4 COM Black
ATX 12V 4PIN (4+4PIN EPS 12V in split mode)
Signal Pin Pin Signal
Black GND 1 3 +12V Yellow
Black GND 2 4 +12V Yellow
10
STRIDER GOLD EVOLUTION SERIES
4PIN peripheral connector (HDD) 4PIN floppy connector (FDD)
Signal Pin Pin Signal
Yellow +12V 1 1 +5VDC Red
Black COM 2 2 COM Black
Black COM 3 3 COM Black
Red +5VDC 4 4 +12V Yellow
6PIN PCI Express connector
Signal Pin Pin Signal
Yellow +12V 1 4 COM Black
Yellow +12V 2 5 COM Black
Yellow +12V 3 6 COM Black
8PIN PCI Express connector
Signal Pin Pin Signal
Yellow +12V 1 5 COM Black
Yellow +12V 2 6 COM Black
Yellow +12V 3 7 COM Black
Black
sense1
COM 4 8 COM Black
SATA connector
Signal Pin
Orange +3.3V 5
Black COM 4
Red +5V 3
Black COM 2
Yellow +12V 1
©2011 SilverStone Technology Co., Ltd. All Rights Reserved.
All specifications are subject to change without prior notice.
