1
Introduction
Introduction
Thank you for purchasing the Ubiquiti Networks
™
TOUGHSwitch
™
PoE PRO, which is part of the TOUGHSwitch series:
Name Model Description
TOUGHSwitch PoE TS-5-POE
5-port managed switch
featuring 24V PoE
TOUGHSwitch PoE PRO TS-8-PRO
8-port managed switch
featuring 24V/48V PoE
TOUGHSwitch PoE CARRIER TS-16-CARRIER
Two TOUGHSwitch PoE
PROs mounted in a rack
This Quick Start Guide is designed to guide you through the
installation and show you how to access the Configuration
Interface. This Quick Start Guide also includes the warranty terms,
and is for use with the TOUGHSwitch PoE PRO, model TS-8-PRO.
For more information, visit www.ubnt.com/toughswitch
Package Contents
8-Port Power over Ethernet
Managed Switch PRO
Model: TS-8-PRO
TOUGHSwitch PoE PRO Power Cord Quick Start Guide
TERMS OF USE: All Ethernet cabling runs must use CAT5 (or above). It is the customer’s responsibility to
follow local country regulations, including operation within legal frequency channels, output power,
indoor cabling requirements, and Dynamic Frequency Selection (DFS) requirements.
