9
GB
Cordless drill/driver
INTENDED USE
This tool is intended for drilling in wood, metal, ceramic and
plastic; tools with electronic speed control and left/right rotation
are also suitable for screwdriving and thread cutting
TECHNICAL SPECIFICATIONS 1
PRODUCT ELEMENTS 2
1 Switch for on/off and speed control
2 Switch for changing direction of rotation
3 Keyless chuck
4 Ring for torque control
5 Switch for selecting mechanical speed
SAFETY
WARNING! Read all instructions. Failure to follow all instruc-
tions listed below may result in electric shock, fi re and/or seri-
ous injury.
• Ensure the switch is in the off position before inserting bat-
tery pack. Inserting the battery pack into power tools that
have the switch on invites accidents.
• Recharge only with the charger specifi ed by the manufac-
turer. A charger that is suitable for one type of battery pack
may create a risk of fi re when used with another battery
pack.
• Use power tools only with specifi cally designated battery
packs. Use of any other battery packs may create a risk of
injury and fi re.
• Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before you
start working
• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the charger (charg-
ers with a rating of 230V or 240V can also be connected to
a 220V supply)
• In case of electrical or mechanical malfunction, immediate-
ly switch off the tool or unplug charger from power source
• SBM Group can assure fl awless functioning of the tool only
when original accessories are used
• Use only accessories with an allowable speed matching at
least the highest no-load speed of the tool
• This tool should not be used by people under the age of 16
years
• Be careful not to drill or drive into areas where electrical
wires may be contacted
• Ensure that switch
is in the middle (locking) position
before making any adjustments or changing accessories
as well as when carrying or storing the tool
• Do not touch the contacts in the charger
• Do not expose tool/charger/battery to rain
• Never charge battery outdoors
• Store tool/charger/battery in locations where temperature
will not exceed 40 °C or drop below 0 °C
• Batteries will explode in fi re, so do not burn battery for any
reason
• When damaged, and under extreme usage and tempera-
ture conditions, batteries may start to leak
- if liquid comes into contact with the skin, wash quickly with
soap and water, then with lemon juice or vinegar
- if liquid gets into the eyes, fl ush eyes with clean water for
a minimum of 10 minutes and seek immediately medical
attention
• When battery is not in tool or charger, it should be kept
away from metal objects such as nails, screws, keys etc. to
prevent short-circuit
• Do not use charger when damaged; take it to one of the of-
fi cially registered SBM Group Service Stations for a safety
check
• Do not use battery when damaged; it should be replaced
immediately
• Do not disassemble charger or battery
• Do not attempt to recharge non-rechargeable batteries with
the charger
• Normally when starting to charge the discharged battery,
red and green LEDs of the battery charger are on. When
the battery is fully charged only green LED is on. If no LEDs
are on while the charger is on, do not use the battery and
the charger and take them to the service center.
• When using your tool continuously, the batteries in your
battery pack will become hot. You should let a hot battery
pack cool down for approximately 30 minutes before at-
tempting to recharge.
• In case of long storage, store the battery in fully charged
condition.
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire in
the cord of the charger to the earth terminal of the plug
• If for any reason the old plug is cut off the cord of the charg-
er, it must be disposed of safely and not left unattended
To ensure longer service life and proper perform-
ance of the battery, take the following actions when
you start using new battery:
1. Use the new battery, without recharging it, till its complete
discharge.
2. Then charge the battery for 3-5 hours.
3. Repeat abovementioned actions (1 and 2) 3-5 times to
reach the nominal battery capacity.
MAINTENANCE
Make sure that the machine is not live when carry-
ing out maintenance work on the motor.
Regularly clean the machine housing with a soft cloth, prefer-
ably after each use. Keep the ventilation slots free from dust
and dirt.If the dirt does not come off use a soft cloth moistened
with soapy water. Never use solvents such as petrol, alcohol,
ammonia water, etc. These solvents may damage the plastic
parts.
The machine requires no additional lubrication.
Should a fault occur, e.g. after wear of a part, please contact
your local SBM Group dealer.
ENVIRONMENT
In order to prevent the machine from damage during transport,
it is delivered in a sturdy packaging. Most of the packaging
materials can be recycled. Take these materials to the appro-
priate recycling locations. Take your unwanted machines to
your local SBM Group dealer. Here they will be disposed of in
an environmentally safe way.
Li-Ion batteries can be recycled. Deliver them to a disposal
site for chemical waste so that they can be recycled or dis-
posed of in an environmentally friendly manner.
English
