Troubleshooting > 172
Error Wait a Moment
Program Data Receiving
Your machine's network card firmware is
being reprogrammed.
Error Wait a Moment
Program Data Received OK
Your machine's network card firmware is
being reprogrammed.
Error Check Data
Program Data Receive Error <%DLCODE%>
An error has occurred while your machine’s
network card firmware is being
reprogrammed.
%DLCODE%
1. File size error.
2. Check-sum error.
3. Invalid printer model number
4. Invalid module I/F version
5. Invalid FAT version
Error Wait a Moment
Program Data Writing
Your machine’s network card firmware is
being reprogrammed.
Error Power Off/On
Program Data Written OK
Your machine's network card firmware has
been reprogrammed successfully.
Error Check Data
Program Data Write Error <%DLCODE%>
An error has occurred while your machine’s
network card firmware is being
reprogrammed.
%DLCODE%
1. Memory allocation error
2. Download file error
3. Device allocation error
4. No device space
5. File writing failure
6. CU-F/W mismatch
Error Shutdown screen
&
Initializing screen
Controller unit is rebooting.
%CODE%:
0 … Reboot due to a reason other than the
following.
1 … Reboot due to PJLCommand.
2 … Reboot in accordance with a menu
change.
3 … Reboot due to quit operator of PostScript
Language.
4 … reboot by Network Utility (including
Web).
Error Shutdown in progress Your machine is shutting down.
Error Please turn off the Power. Shutdown complete.
Error Lamp Error. Please call service. Indicates that a lamp error has occurred.
Confirm that this message appears on the
touch screen.
If the code still appears, contact your dealer.
Error ADF Motor FAN LOCK Error Indicates that a fan lock error for ADF motor
has occurred.
If the code still appears, contact your dealer.
STATUS /
CODE
MESSAGE MEANING / ACTION
