![OKI MC851+ [174/186] Message meaning action](/views2/1073933/page174/bgae.png)
Troubleshooting > 174
Error Searching for Address Failed Cannot find out the target address from the
LDAP server.
Error Search Results Exceeded the Limit Search results from LDAP server exceeded
the upper limit.
Error Search Root Error Search root not found in LDAP server.
Error Address Search Time-out Search failed; time-out error.
Error Getting Target IP Failed
Check DHCP Settings
DHCP server not found.
Note: Scan to Email, Scan to Network PC and
Scan to Remote PC are unavailable during
this status.
Error Check DNS Settings
Press <Stop> key
Failed to connect with DNS server.
Error Check Server Settings
Press <Stop> key
Failed to connect with file server.
Error Server Login Failed
Press <Stop> key
Failed to login in CIFS or FTP server.
Error Entering Directory Failed
Press <Stop> key
Failed to access directory in FTP server.
Error Changing Data Transfer Type Failed
Press <Stop> key
Indicates that the data transfer type is not
supported in the FTP server.
Change the data transfer type in FTP server.
Error File Writing Failed
Press <Stop> key
Failed to save image file in file server during
Scan to Network PC execution.
Error Storage Space Full
Press <Stop> key
File sending failed due to insufficient free
space in storage device (FTP Server).
Error Change File Name
Press <Stop> key
File sending failed due to a problem with the
file name (FTP Server).
Error Unsupported Server
Press <Stop> key
Indicates that the server does not support
CIFS/FTP.
Error Check Network Share Name
Press <Stop> key
Indicates that the network folder name is
wrong (CIFS server).
Error Check Data
Program Data Write Error <%DLCODE%>
An error has occurred while writing the SIP
download data.
%DLCODE%
1. Data transfer error
2. No device space
3. Check sum error
4. Chip detection error
5. Chip erase error
6. Chip writing error
7. Chip verify error
8. Data error (product code is wrong, etc.)
9. Data size error
STATUS /
CODE
MESSAGE MEANING / ACTION
