ML1120/ML1190 eco User’s Guide – Operating instructions > 66
Serial I/F Parity Set Parity. None
Odd
Even
Ignore
Serial Data
7/8 Bits
Set serial data
length.
8 bit
7 bit
Protocol Set protocols. DTR
X-ON/X-OFF
DTR & X-ON/X-OFF
Diagnostic
Test
Set/Cancel loop
testing of the serial
interface.
No
Yes
Baud Rate Set the
transmission speed
of the serial
interface.
9,600 bps
4,800 bps
2,400 bps
1,200 bps
600 bps
300 bps
19,200 bps
DTR Signal Set whether to
switch the DTR
signal of the serial
interface by Select/
Deselect or hold it
after power-on.
Ready on Power UP
Ready on Select
Busy Time Set the minimum
time it takes to
switch from a busy
state to a ready
state.
0.2 sec
1.0 sec
