ML1120/ML1190 eco User’s Guide – Operating instructions > 77
Parallel I/F I-Prime Set I-Prime signal
control of the
Centronics
interface.
Invalid
Buffer Print
Buffer Clear
Auto Feed XT Set whether to
enable or disable
Auto Feed XT signal
of the Centronics
interface.
(EPSON emulation
only)
Valid
Invalid
Bi-Direction Set whether to
enable or disable
Two-way
communication of
the Centronics
interface.
Enable
Disable
Serial I/F
Menu
Parity Set parity. None
Odd
Even
Ignore
Serial Data 7/8
Bits
Set serial data
length.
8 bit
7 bit
Protocol Set protocols. DTR
X-ON/X-OFF
DTR & X-ON/X-OFF
Diagnostic Test Set/Cancel loop
testing of the serial
interface.
No
Yes
Baud Rate Set the transmission
speed of the serial
interface.
9,600 bps
4,800 bps
2,400 bps
1,200 bps
600 bps
300 bps
19,200 bps
