ML1120/ML1190 eco User’s Guide – Troubleshooting > 82
T
ROUBLESHOOTING
C
LEARING
PAPER
JAMS
C
UT
SHEET
PAPER
JAMMED
IN
PRINTER
1. Set the Power Switch to OFF.
2. Remove the Access Cover.
3. Set the Paper Thickness lever to the Replace Ribbon
position (position 6).
4. Remove the ribbon cartridge. See “Changing a ribbon
cartridge” on page 95.
WARNING!
Do not carry out any operations inside the printer with
the Power Switch set to ON.
WARNING!
The Print Head may be hot after printing. Allow it to
cool before touching it.
