![Icom IC-M73 Plus [47/56] 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16](/views2/1074267/page47/bg2f.png)
New2001
39
13
SPECIFICATIONS
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
D Transmitter
• Output power : 6 W/3 W/1 W/0.5 W*
*
German version only
• Modulation system : Variable reactance frequency
modulation
• Max. frequency deviation : ±5 kHz
• Adjacent channel power : 70 dB
• Spurious emissions : 0.25 µW
D Receiver
• Sensitivity (typical) : –4 dBµ emf at 20 dB SINAD
• Squelch sensitivity (threshold) : –5 dBµ emf (typical)
• Intermodulation rejection ratio : 68 dB
•
Spurious response rejection ratio
: 70 dB
• Adjacent channel selectivity : 70 dB
• Audio output power (at 10% distortion with an
8 ˘ load)
: 0.2 W (External)
0.7 W typical at 1 kHz (Internal)
• IC-M73EURO (AUS version)
D General
• Frequency coverage : Tx 156.025–157.425 MHz
: Rx 156.300–162.025 MHz
• Mode : FM (16K0G3E)
• Operating temperature range : –10°C to +55°C
• Current drain (at 7.4 V) : TX high 1.4 A
(approximately) Max. audio 0.45 A
• Power supply requirement :
7.4 V DC nominal (negative
ground)
• Frequency stability : ±10 ppm (–10°C to +55°C)
• Antenna impedance : 50 ˘ nominal
• Dimensions (approximately) : 52.5(W) × 125(H) × 30(D)mm
(Projections not included) : 2.0(W) × 4.9(H) × 1.2(D) inches
• Weight (approximately) : 280 g/9.9 oz with BP-245N
D Transmitter
• Output power : 5 W/3 W/1 W
• Modulation system : Variable reactance frequency
modulation
• Max. frequency deviation : ±5.0 kHz
• Adjacent channel power : 70 dB
• Spurious emissions (typical) : 0.25 µW
D Receiver
• Sensitivity (typical) : –5 dBµ emf (20 dB SINAD)
• Squelch sensitivity (at threshold, typical)
: –6 dBµ emf
• Intermodulation rejection ratio : 65 dB
•
Spurious response rejection ratio
: 65 dB
• Adjacent channel selectivity : 65 dB
• Audio output power (at 10% distortion with an 8 ˘ load)
: 0.2 W (External)
: 0.7 W typical at 1 kHz (Internal)
All stated specications are subject to change without notice or obligation.
