Icom IC-FR3000 [20/24] Specifications and options
![Icom IC-FR3000 [20/24] Specifications and options](/views2/1074335/page20/bg14.png)
6
15
SPECIFICATIONS AND OPTIONS
■ Specifications
Specifications are measured in accordance with EIA/TIA-603.
DD
IC-FR3000
General
• Frequency coverage : 150.000–174.000 MHz*
148.000–172.000 MHz*
* Depends on version
• Channel specing : 12.5/25.0 kHz (Narrow/Wide)
• PLL channel step : 5.0, 6.25 kHz (2.5 kHz repeater
operation only)
• Frequency stability : ±2.5 ppm
• Number of channels : Max. 32 channel
• Antenna connector : Type-N× 2 (50 Ω)
• Operating temp. range : –30°C to +60°C
(–22°F to +140°F)
• Power supply voltage : 100–120 V AC (50/60 Hz)*
220–240 V AC (50/60 Hz)*
13.6 V DC (negative ground)
* Depends on version
• Current drain (at 13.6 V) : TX high (50 W) 15.0 A
Max. audio 2.0 A
Stand-by 1.0 A
• Dimensions : 410(W) × 110(H) × 360(D) mm
(Projections not included) 16
1
⁄
3(W) × 4
1
⁄
3(H) × 14
1
⁄
4(D) in
• Weight (approx.) : 12 kg; 26 lb 7 oz
Transmitter
• RF output power : 50 W
• Modulation system : Variable reactance frequency
modulation system
• Max. frequency deviation : ±5.0 kHz (Wide),
±2.5 kHz (Narrow)
• Spurious emissions : 70 dB
• Adjacent channel power : More than 70 dB (Wide),
More than 60 dB (Narrow)
• Audio harmonic distortion : 3.0% typical
(at 1 kHz, 40% deviation)
• Hum and noise : More than 40 dB (Wide),
More than 34 dB (Narrow)
• Microphone impedance : 600 Ω (8-pin modular)
Receiver
• Receive system : Double conversion
superheterodyne system
• Sensitivity (12 dB SINAD) : 0.25 µV typical
• Intermediate frequencies : 1st; 31.65 MHz, 2nd; 455 kHz
•
Adjacent channel selectivity
: More than 70 dB (Wide),
More than 60 dB (Narrow)
• Spurious response : More than 70 dB
• Intermodulation : More than 70 dB
• Hum and noise : More than 40 dB (Wide),
More than 34 dB (Narrow)
• Audio output power : 2.5 W typical at 10% distortion
with a 4 Ω load
•
External speaker connector
:
2-conductor 3.5 (d) mm (
1
⁄
8") 4 Ω
DD
IC-FR4000
General
• Frequency coverage : 400.000–430.000 MHz*
430.000–450.000 MHz*
450.000–480.000 MHz*
* Depends on version
• Channel specing : 12.5/25.0 kHz (Narrow/Wide)
• PLL channel step : 5.0, 6.25 kHz
• Frequency stability : ±1.5 ppm*/±2.5 ppm*
* Depends on version
• Number of channels : Max. 32 channel
• Antenna connector : Type-N × 2 (50 Ω)
• Operating temp. range : –30°C to +60°C
(–22°F to +140°F)
• Power supply voltage : 100–120 V AC (50/60 Hz)*
220–240 V AC (50/60 Hz)*
13.6 V DC (negative ground)
* Depends on version
• Current drain (at 13.6 V) : TX high (50 W) 20.0 A
Max. audio 2.0 A
Stand-by 1.0 A
• Dimensions : 410(W) × 110(H) × 360(D) mm
(Projections not included) 16
1
⁄
3(W) × 4
1
⁄
3(H) × 14
1
⁄
4(D) in
• Weight (approx.) : 12 kg; 26 lb 7 oz
All stated specifications are subject to change without notice or obligation.
