Icom IC-PW1 [19/20] Specifications
![Icom IC-PW1 [19/20] Specifications](/views2/1074372/page19/bg13.png)
5
SPECIFICATIONS
16
■General
•Frequency coverage: 01.800–01.999 MHz
03.500–13.999 MHz
07.000–17.300 MHz
10.100–10.150 MHz
14.000–14.350 MHz
18.068–18.168 MHz
21.000–21.450 MHz
24.890–24.990 MHz*
1
28.000–29.700 MHz*
1
50.000–54.000 MHz
*
1
The U.S.A. version can only be
used the antenna tuner on the
24–28 MHz bands.
•Antenna connector :
Input PL-239×2 (50 Ω)
Output PL-239×4 (50 Ω)
•Usable temperature : –10°C to 40°C (14°F to 104°F)
range
•Power supply requirement:
non-Europe versions
100–120 V AC or
200–240 V AC (±10 %)
Europe version 230 V AC (±10 %)
•Dimensions (W × H × D):
Linear amplifier 350 × 265 × 375 mm
13
25
⁄32 × 10
7
⁄16 × 14
3
⁄4 in
Remote controller 205 × 71 × 68.3 mm
8
1
⁄16 × 2
25
⁄32 × 2
11
⁄16 in
(Projections not included)
•Weight : 25 kg (55 lb)
(incl. remote controller)
•CI-V connector : 2-conductor 3.5(d) mm (
1
⁄8")
■Transmitter
•Output power :
•Driving power : 100 W max.
•Spurious emissions : –60 dB (HF bands)
–70 dB (50 MHz band)
•SEND connector : Phono (RCA)
•ALC connector : Phono (RCA)
■Antenna tuner
•Matching impedance range:
HF bands*
2
16.7 to 150 Ω unbalanced
(Less than VSWR 3:1)
50 MHz band 20 to 125 Ω unbalanced
(Less than VSWR 2.5:1)
*
2
The U.S.A. version can only be tuned within 1.80–1.95
MHz of the 1.8 MHz band.
•Minimum operating : 60 W
input power
•Tuning accuracy : VSWR 1.5:1 or less
•Insertion loss : Less than 1.0 dB
(after tuning)
MODE
INPUT AC VOLTAGE
200–240 V AC 100–120 V AC
CW, RTTY 1 kW 500 W
SSB 1 kW PEP 500 W PEP
DECLARATION
OF CONFORMITY
Icom Inc. Japan
6-9-16, Kamihigashi, Hirano-ku
Osaka 547-0002, Japan
Kind of equipment: HF+50 MHz 1 KW LINEAR AMPLIFIER
Type-designation: IC-PW1 + opC-853
Signature
Authorized representative name
Place and date of issue
T. Aoki
General Manager
Icom (Europe) GmbH
Himmelgeister straße 100
D-40225 Düsseldorf
Düsseldorf 14D. Dec. 1998
Icom (Europe) GmbH
These equipments comply with the European harmonised standard
ETS300 684 (EMC product standard for Commercially Available
Amateur Radio Equipment).
These equipments also comply with the requirements of the 73/23/EEC
directive for electrical safety. This compliance is based upon the
harmonised CENELEC generic standard EN60 065: 1993 +A11.
(Report No.: E 9861504 E 01 and E 9860764 E 01 by TÜV Rheinland
Germany)
Versions of the IC-PW1 which dis-
play “CE” on the serial number seal,
comply with the essential require-
ments of the 89/336/EEC directive
for Electromagnetic Compatibility.
NOTE: To meet European EMC regulations,
the OPC-853 AC cable with EMC filter must be
connected to the IC-PW1 Europe version.
