![Icom IC-F310 [18/20] Optional smartrunk ii operation](/img/pdf.png)
Icom IC-F310 [18/20] Optional smartrunk ii operation
![Icom IC-F320 [18/20] Optional smartrunk ii operation](/views2/1074525/page18/bg12.png)
4
OPTIONAL SmarTrunk II™ OPERATION
15
D Clear channel alerting
If all channels are busy, the transceiver automatically begins
searching for an open channel and beeps every ten seconds.
When two short beeps (low-pitched, then high-pitched) are
heard, a channel is available. Push [M], [M] immediately to re-
dial the last number.
NOTE: For additional operating instructions, contact your
dealer or system operator.
