16
5
CONNECTIONS AND MAINTENANCE
■ Dimensions
152 mm (6 in)
178 mm (7 in)
67 mm (2
5
⁄8 in)
51 mm (2 in)
28.5 mm
(1
1
⁄8 in)
86.5 mm (3
13
⁄32 in) 25 mm
(1 in)
