4
2
PANEL DESCRIPTION
■ Function display
q TRANSMIT INDICATOR
Appears while transmitting. (p. 8)
w BUSY INDICATOR
Appears when receiving a signal or when [SQUELCH] is
rotated too far clockwise. (p. 7)
e CHANNEL INDICATOR
Shows the operating channel (pgs. 5, 6)
r TAG CHANNEL INDICATOR
Appears when the selected channel is set as a tag chan-
nel. (p. 9)
t DUALWATCH INDICATOR
Appears and flashes during dualwatch operation. (p. 7)
y TRI-WATCH INDICATOR
Appears and flashes during tri-watch operation. (p. 7)
u SCAN INDICATOR
Appears and flashes during scan operation. (p. 9)
i DUPLEX INDICATOR
Appears when the selected channel is a duplex channel.
(p. 6)
o CALL CHANNEL INDICATOR
Appears when the call channel is selected. (p. 5)
!0 WEATHER ALERT INDICATOR
“ALT” appears when a weather alert function is turned ON.
(pgs. 6, 12)
!1 MODE INDICATORS (p. 5, 6)
➥ “USA” shows that USA channels are selected.
➥ “CAN” shows that Canadian channels are selected.
➥ “INT” shows that international channels are selected.
➥ “WX” shows that weather channels are selected.
!2 LOW POWER INDICATOR
Shows that low output power is selected. (p. 8)
LOW CALL
CANUSA
INT
WX ALT
TX
TAG
DUAL
SCAN
DUP
TRI
BUSY
wq erty
u
i
o
!2
!1
!0
