SiBE041010EA Specifications
Specifications 6
50 Hz, 230 V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Unit FTX35JV1B
Outdoor Unit
RX35JV1B
Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 3.3 (1.3 ~ 3.8) 3.5 (1.3 ~ 4.8)
Btu/h 11,300 (4,400 ~ 13,000) 11,900 (4,400 ~ 16,400)
kcal/h 2,840 (1,120 ~ 3,270) 3,010 (1,120 ~ 4,130)
Running Current (Rated) A 5.2 4.7
Power Consumption
Rated (Min. ~ Max.)
W 980 (290 ~ 1,300) 930 (290 ~ 1,290)
Power Factor % 81.9 86.0
COP Rated (Min. ~ Max.) W/W 3.37 (4.48 ~ 2.92) 3.76 (4.48 ~ 3.72)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 9.5
Drain mm φ 18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15
Max. Interunit Height Difference m 12
Chargeless m 10
Amount of Additional Charge
of Refrigerant
g/m 20
Indoor Unit FTX35JV1B
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
9.3 (328) 10.1 (356)
M
7.7 (272) 8.4 (295)
L
6.1 (215) 6.7 (235)
SL
4.9 (173) 5.7 (201)
Fan
Type Cross Flow Fan
Motor Output W 16
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 283 × 770 × 198
Packaged Dimensions (H × W × D) mm 263 × 840 × 344
Weight (Mass) kg 7
Gross Weight (Gross Mass) kg 11
Sound
Pressure
Level
H / M / L / SL dB(A) 41 / 34 / 27 / 23 41 / 35 / 29 / 26
Sound Power Level dB 57 57
Outdoor Unit RX35JV1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23AEXD
Motor Output W 750
Refrigerant
Oil
Type FVC50K
Charge L 0.375
Refrigerant
Type R-410A
Charge kg 1.0
Airflow Rate H
m³/min
(cfm)
27.6 (975) 24.5 (865)
Fan
Type Propeller
Motor Output W 33
Running Current (Rated) A 5.02 4.52
Power Consumption (Rated) W 940 890
Power Factor % 86.0 85.6
Starting Current A 5.0
Dimensions (H × W × D) mm 550 × 658 × 275
Packaged Dimensions (H × W × D) mm 616 × 788 × 359
Weight (Mass) kg 30
Gross Weight (Gross Mass) kg 34
Sound Pressure Level (H) dB(A) 48 48
Sound Power Level (H) dB 62 62
Drawing No. 3D065932
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
