Troubleshooting SiBE041010EA
51 Service Diagnosis
4. Troubleshooting
4.1 Error Codes and Description
: Displayed only when system-down occurs.
Error Codes Description
Reference
Page
System
00
Normal —
U0
Refrigerant shortage 57
U2
Low-voltage detection or over-voltage detection 59
U4
Signal transmission error (between indoor unit and outdoor unit) 61
UA
Unspecified voltage (between indoor unit and outdoor unit) 63
Indoor
Unit
A1
Indoor unit PCB abnormality 52
A5
Freeze-up protection control or heating peak-cut control 53
A6
Fan motor (DC motor) or related abnormality 54
C4
Indoor heat exchanger thermistor or related abnormality 56
C9
Room temperature thermistor or related abnormality 56
Outdoor
Unit
E1
Outdoor unit PCB abnormality 64
E5
OL activation (compressor overload) 65
E6
Compressor lock 67
E7
DC fan lock 68
E8
Input overcurrent detection 69
EA
Four way valve abnormality 70
F3
Discharge pipe temperature control 72
F6
High pressure control in cooling 73
H0
Compressor system sensor abnormality 74
H6
Position sensor abnormality 75
H8
DC voltage / current sensor abnormality 77
H9
Outdoor temperature thermistor or related abnormality 78
J3
Discharge pipe thermistor or related abnormality 78
J6
Outdoor heat exchanger thermistor or related abnormality 78
L3
Electrical box temperature rise 80
L4
Radiation fin temperature rise 81
L5
Output overcurrent detection 83
P4
Radiation fin thermistor or related abnormality 78
