![Daikin EHYHBH05AAV32 [115/136] Technical data](/views2/1746854/page115/bg73.png)
15 Technical data
Installer reference guide
115
EVLQ05+08CAV3 + EHYHBH05AA + EHYHBH/X08AA +
EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1A – 2016.02
Heating only type Reversible type
Outdoor units EVLQ05CAV3 EVLQ08CAV3 EVLQ08CAV3
Indoor units EHYHBH05 EHYHBH08 EHYHBX08
Specifications Length 845mm
Nr. of rows 2
Fin pitch 1.8mm
Nr. of passes —
Face area —
Nr. of stages 32
Tube type Hi-Xa(8)
Fin Type WF fin
Treatment Anti-corrosion treatment (PE)
Fan
Type Propeller
Quantity 1
Air flow rate (nominal at 230V) Heating 45m³/min 47m³/min
Cooling 52.5m³/min
Discharge direction Horizontal
Motor Quantity 1
Output 53W
Compressor
Quantity 1
Motor Model 2YC36BXD#C 2YC45NXD#C
Type Hermetically sealed swing compressor
Output —
PED
Category of unit I (excluded from scope of PED due to article 1, item 3.6 of 97/23/EC)
Most critical part —
PS×V —
PS×DN —
Operation range
1
Heating (outdoor unit) Minimum –25°CDB
Maximum 25°CDB
Sound level
Nominal - Heating Sound power 61dBA 62dBA
Sound pressure
2
48dBA 49dBA
Night quiet Sound pressure —
Refrigerant
Type R410A
Charge 1.45kg 1.60kg
Control Expansion valve (electronic type)
Nr. of circuits 1
Refrigerant oil
Type FVC50K
Charged volume 0.65l 0.8l
Piping connections
Liquid Type Flare connection
Diameter (OD) Ø6.35mm
Gas Type Flare connection
Diameter (OD) Ø15.9mm
(1)
See operation range drawing.
(2)
The sound pressure level is measured via a microphone at a certain distance from the unit. It is a relative value depending
on the distance and acoustic environment. Refer to the sound spectrum drawing for more information.
