Icom IC-R1500 Инструкция по эксплуатации онлайн [5/56] 69206
![Icom IC-R1500 Инструкция по эксплуатации онлайн [5/56] 69206](/views2/1074689/page5/bg5.png)
iv
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
■ AFC function ................................................................................ 13
■ VSC function ................................................................................ 13
■ IF filter selection ........................................................................... 14
■ IF shift function ............................................................................. 14
■ Duplex operation .......................................................................... 15
5 MEMORY OPERATION ............................................................ 16–24
■ General description ...................................................................... 16
■ Memory channel selection ........................................................... 16
■ Programming a memory channel ................................................. 17
■ Programming channel names ..................................................... 18
■ Copying memory contents ........................................................... 19
■ Memory clearing .......................................................................... 21
■ Memory bank setting .................................................................... 22
■ Memory bank selection ................................................................ 23
■ Transferring bank contents .......................................................... 23
6 SCAN OPERATION .................................................................. 25–29
■ Scan types ................................................................................... 25
■ Scan start/stop ............................................................................. 26
■ Scan edges programming ............................................................ 27
■ Skip scan ..................................................................................... 28
■ Scan resume condition ................................................................ 29
7 PRIORITY WATCH .......................................................................... 30
■ Priority watch types ...................................................................... 30
■ Priority watch operation ............................................................... 30
8 POCKET BEEP AND TONE SQUELCH ................................... 31–34
■ Pocket beep operation ................................................................. 31
■ Tone/DTCS squelch operation ..................................................... 33
■ Tone scan ..................................................................................... 34
9 SET MODE ................................................................................ 35–41
■ General ........................................................................................ 35
■ Set mode items ............................................................................ 35
10 OTHER FUNCTIONS ................................................................ 42–46
■ Weather channel operation .......................................................... 42
■ DSP operation .............................................................................. 43
■ DATA cloning ................................................................................ 44
■ Partial reset................................................................................... 45
■ All reset......................................................................................... 45
■ Internal audio switch..................................................................... 46
11 TROUBLESHOOTING .................................................................... 47
12 DOC ................................................................................................. 48
