Icom IC-R1500 [7/56] Antennal installation
![Icom IC-R1500 [7/56] Antennal installation](/views2/1074689/page7/bg7.png)
2
1
CONNECTION
1
DD
OPC-1156 connection
q Connect the controller plug to the OPC-1156 joint.
w Detach the ferrite core from the controller cable, then at-
tach it to the OPC-1156 as shown below.
• Make sure to roll the cable to the ferrite core.
e Connect the OPC-1156 plug to the [CONTROLLER] con-
nector of the receiver.
■ Antennal installation
D Antenna location
To obtain maximum performance from the receiver, select a
high-quality antenna and mount it in a good location. A non-
radial antenna should be used when using a magnetic mount.
Receiver
OPC-1156
Controller
Joint
Ferrite core
