Karcher HD 5/11 C [18/244] Technical specifications

Karcher HD 5/11 C [18/244] Technical specifications
– 8
Technical specifications
1.520-101.0
1.520-103.0
1.520-104.0
1.520-107.0
1.520-111.0
1.520-106.0 1.520-102.0
Main Supply
Voltage V * 230 110
Current type Hz 1~ 50
Connected load kW 2,2 1,6
Protection (slow, char. C) A 16 10 15
Type of protection IPX5
Extension cord 30 m mm
2
2,5
Water connection
Max. feed temperature °C 60
Min. feed volume l/h (l/min) 600 (10)
Suck height from open container (20 °C) m 1
Max. feed pressure MPa (bar) 1,2 (12)
Performance data
Working pressure MPa (bar) 11,5 (115) 9,5 (95)
Nozzle size (CX) 036 033
Max. operating over-pressure MPa (bar) 13 (130) 12 (120)
Flow rate l/h (l/min) 500 (8,3) 410 (6,8)
Detergent suck in l/h (l/min) 0...25 (0...0,42)
Max. recoil force of hand spray gun N 21
Values determined as per EN 60355-2-79
Hand-arm vibration value
Hand spraygun m/s
2
2,55
Spray lance m/s
2
<2,5
Uncertainty K m/s
2
1
Sound pressure level L
pA
dB(A) 73
Uncertainty K
pA
dB(A) 2
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 88
Dimensions and weights
Length mm 360
Width mm 375
Height mm 925
Weight without accessories kg 25 23,8
* 1.520-101.0, 1.520-103.0: 230 V; 1.520-104.0: 230...240 V; 1.520-107.0: 240 V;
1.520-111.0: 220 V
18 EN
