Error Codes and Description of Fault Si10-417
22 Service Diagnosis
4.2 Outdoor Unit
Code
Indication
Description of Problem
Classification No. and
related page
3
4
5
6
A5
Anti-icing function — — — 35
Freeze-up protection — — 37 —
E5
OL activation (compressor
overloaded)
39 40 41 39
E6
Compressor lock 43 44 45 47
E7
DC fan lock —484948
E8
Input over current detection 50 52 54 56
EA
Four way valve abnormality 58 60 62 64
F3
Discharge pipe temperature
control
66 68 70 72
F6
High pressure control in cooling 74 74 — 75
H6
Position sensor abnormality 77 79 81 83
H8
CT or related abnormality 85 87 89 91
H9
Outdoor air thermistor or related
abnormality
93 93 95 97
J3
Discharge pipe thermistor or
related abnormality
93 93 95 97
J6
Heat exchanger thermistor or
related abnormality
93 93 95 97
J8
Liquid pipe thermistor or related
abnormality
——9597
J9
Gas pipe thermistor or related
abnormality
——9597
L3
Electrical box temperature rise 99 101 103 105
L4
Radiation fin temperature rise 107 109 111 113
L5
Output over current detection 115 115 118 121
P4
Radiation fin thermistor or related
abnormality
93 93 95 97
Si10-417.fm Page 22 Wednesday, September 22, 2004 6:38 PM
