Si10-417 Troubleshooting
Service Diagnosis 93
5.2.34 Thermistor or Related Abnormality
(Outdoor Unit)
Remote
Controller
Display
P4, J3, J6, H9
Method of
Malfunction
Detection
This type of error is detected by checking the thermistor
input voltage to the microcomputer.
[A thermistor error is detected by checking the
temperature.]
Malfunction
Decision
Conditions
The thermistor input is above 4.96 V or below 0.04 V
with the power on.
Error J3 is judged if the discharge pipe thermistor
temperature is smaller than the condenser thermistor
temperature.
Supposed
Causes
Connector in poor contact
Thermistor defective
Outdoor unit PCB defective
Indoor unit PCB defective
Condenser thermistor defective in the case of J3 error
(outdoor unit heat exchanger thermistor in the cooling
mode, or indoor unit heat exchanger thermistor in the
heating mode)
Si10-417.fm Page 93 Wednesday, September 22, 2004 6:38 PM
