Si04-604 Indoor Unit
Removal Procedure 149
2. Remove the signal
receiver PCB.
1
Release the hook with a
flat screwdriver.
2
Release the hook and
remove the receiver
unit.
3
Release the 2 hooks
and remove the signal
receiver PCB.
Step
Procedure Points
