Outdoor Unit Si04-604
168 Removal Procedure
4
Pull the sound blanket
(inner) out.
Since the piping ports on the
sound blanket are torn
easily, remove the blanket
carefully.
5
Pull the sound blanket
(bottom) out.
Step
Procedure Points
