PDM20 Series
- 21 -
Function
code
Description Set range Unit Default
Display
level
Modific
ation
level
Notes
P0.09
PID sleep
detection
delay
0.0～
120.0
s 1.0 ○
In small water
consumption, if sleeping
is slow or it can’t sleep,
make the value smaller;
if it sleeps in advance or
it starts and stops
frequently, make the
value bigger.
P0.10
PID wakeup
detection
delay
0.0～
120.0
s 1.0 ○
PID wakeup detection
delay
P0.11
Low level
hold
frequency of
PID sleeping
detection
0.0～
60.00
Hz 35.00 ○
RPID runs at sleep
holding frequency.
After the time P0.12,
PID enters sleeping
mode.
P0.12
Running time
of
PID Low level
hold
frequency
0.0～
3600
s 3.0 ○
Running time at low
frequency in sleep mode
1
P0.13
PID sleep
deviation
pressure
0.0～
P0.01
bar 0.1 ○
When actual pressure is
larger than (set pressure
minus sleep deviation
pressure), system starts
to handle with sleep.
P0.14
Automatically
start self-reset
at power on
00～11
10 ○
Ones：auto-start choices
0：OFF
1：ON
Tens：fault self-reset
choices
0：OFF
1：ON
By default, self-reset is
ON and auto-start is
OFF.
